INSIZE ISD-V400A Manual Vision Measuring System

INSIZE ISD-V400A Manual Vision Measuring System

The INSIZE ISD-V400A Manual Vision Measuring System is a large-format optical measurement system designed for accurate, non-contact dimensional inspection of precision-manufactured components. With a 400 × 300 × 150 mm X/Y/Z measuring range, the ISD-V400A provides substantially more measurement area than smaller desktop vision systems while maintaining the precision and flexibility required for professional inspection applications.

The system combines a precision manual measuring stage, zoom optics, digital imaging, adjustable LED illumination, and measurement software to allow operators to inspect dimensions, profiles, holes, angles, radii, and other visible features without physically contacting the workpiece.

The ISD-V400A provides 0.5 µm X/Y/Z resolution, 2 µm X/Y repeatability, and X/Y accuracy of ≤(2.5 + L/100) µm, where L is the measuring length in millimeters. The optical system provides approximately 29X–184X magnification on a 21.5-inch monitor.

Key Features

• 400 × 300 × 150 mm measuring range

• Large 606 × 466 mm stage

• 450 × 350 mm glass stage

• 0.5 µm X/Y/Z resolution

• 2 µm X/Y repeatability

• X/Y accuracy of ≤(2.5 + L/100) µm

• 0.7X–4.5X zoom objective

• 29X–184X magnification on a 21.5" monitor

• 92 mm working distance

• 1/3" color CCD camera with 0.3 MP resolution

• Adjustable surface and contour LED illumination

• Manual X/Y/Z positioning

• Maximum workpiece height of 150 mm

• Maximum workpiece weight of 20 kg

• Windows 10/11 operating system

• 110/220V, 50/60Hz power supply

Large 400 × 300 mm Measuring Range

The ISD-V400A is designed for applications where a larger measuring area is required without moving to a fully automated CNC vision measuring system.

Its 400 × 300 mm X/Y measuring range provides ample space for larger components, multiple features, fixtures, and inspection layouts. The 150 mm Z-axis range accommodates workpieces up to 150 mm in height.

The large 606 × 466 mm stage and 450 × 350 mm glass stage provide a stable platform for positioning components during inspection.

Precision Optical Measurement

The ISD-V400A uses a 0.7X–4.5X zoom objective with a 92 mm working distance.

The optical system provides approximately 29X–184X magnification when displayed on the included 21.5-inch monitor, allowing operators to visually inspect and measure small features while maintaining a relatively large overall measuring envelope.

The non-contact optical measurement method is particularly useful when measuring components where physical contact could interfere with the inspection process or where profiles and edges need to be examined visually.

Adjustable LED Illumination

The ISD-V400A incorporates adjustable LED illumination for both surface and contour inspection.

Surface illumination helps illuminate features located on the top surface of the workpiece, while contour illumination can highlight edges and profiles.

Adjustable brightness allows the operator to optimize the image for different materials, geometries, and inspection features.

Manual Operation

The ISD-V400A uses a manual drive system, allowing the operator to position the X, Y, and Z axes during inspection.

This configuration is particularly useful for inspection environments where an operator needs direct control over positioning and measurement rather than fully automated CNC operation.

The system is well suited to:

• First-article inspection

• Prototype inspection

• Tool and die inspection

• Mold inspection

• Quality-control inspection

• Dimensional verification

• Low- and medium-volume inspection

• Laboratory measurement

• Precision component inspection

Measurement Capabilities

The ISD-V400A can be used for a broad range of non-contact dimensional inspection tasks, including:

• Linear dimensions

• Outside dimensions

• Inside dimensions

• Hole diameters

• Hole locations

• Center-to-center measurements

• Angles

• Radii

• Arcs

• Profiles

• Contours

• Edge inspection

• Feature-to-feature measurements

• Dimensional verification

• Comparative inspection

The ISD-V Series is intended for non-contact measurement of planar dimensions, contours, hole positions, angles, and similar visible features.

Applications

The large measuring area makes the ISD-V400A particularly useful for inspecting:

• CNC-machined components

• Precision metal parts

• Molded components

• Stamped components

• Tooling

• Dies

• Fixtures

• Electronic components

• Mechanical components

• Precision hardware

• Industrial components

Industries

• CNC & Precision Machining

• Tool & Die Manufacturing

• Mold Manufacturing

• Automotive

• Aerospace Components

• Electronics

• Medical Device Manufacturing

• Precision Engineering

• Industrial Manufacturing

• Quality Assurance

• Metrology

• Research & Development

Technical Specifications

Product spec sheet PDF

Why Choose the ISD-V400A?

The ISD-V400A provides a combination of large measuring capacity and precision optical inspection in a manually operated platform.

Its 400 × 300 mm X/Y measuring range makes it appropriate for customers who need to inspect larger components or multiple features while retaining the ability to perform detailed optical measurements.

With 0.5 µm resolution and 2 µm repeatability, the ISD-V400A is designed for professional dimensional inspection in manufacturing, quality-control, and metrology environments.

Ideal for Customers Who Need:

• A large optical measuring area

• Non-contact dimensional inspection

• Manual operator-controlled measurement

• Precision measurement of larger components

• Profile and contour inspection

• Adjustable surface and contour illumination

• A 150 mm Z-axis measuring capacity

• Up to 20 kg workpiece capacity

Standard Configuration

The ISD-V400A is part of INSIZE's ISD-VxxA/ISD-VxxH Manual Vision Measuring System family. The standard platform includes the manual measuring machine, optical system, camera, adjustable illumination, computer/measurement system, and associated calibration and operating equipment according to the manufacturer's configuration.

Product Information

Manufacturer: INSIZE
Product Series: ISD-VxxA / ISD-VxxH
Model: ISD-V400A
Product Type: Manual Vision Measuring System
Measurement Method: Non-contact optical measurement
Drive System: Manual
Measuring Range: 400 × 300 × 150 mm
Maximum Workpiece Weight: 20 kg
