INSIZE 2944-1 Digital Chamfer Height Gauge
Call/Text/Email before you buy.
Our team reviews every order and is happy to answer questions about compatibility, specs, or lead times. Don't guess — let's get it right the first time.
INSIZE 2944-1 Digital Chamfer Height Gauge
The INSIZE 2944-1 Digital Chamfer Height Gauge is a specialized precision measuring tool designed for accurately checking chamfer dimensions during machining, fabrication, inspection, and quality control. Its dedicated chamfer-measuring design allows operators to quickly verify small chamfer dimensions directly on a workpiece without relying on visual estimation or conventional measurement methods.
With a 0.2–5 mm (0.008–0.197") measuring range, ±0.02 mm accuracy, and 0.01 mm (0.0005") resolution, the 2944-1 is well suited for inspection applications where consistent chamfer dimensions are important to part quality and fit.
Key Features
-
Dedicated chamfer measurement design for inspecting chamfer dimensions
-
0.2–5 mm measuring range for small chamfers
-
±0.02 mm accuracy for precision inspection
-
0.01 mm / 0.0005" resolution
-
Digital measurement for quick, easy-to-read results
-
Compact design for use directly at the machine or inspection station
-
Suitable for production inspection, incoming inspection, and quality control
Precision Chamfer Inspection
Chamfers are commonly incorporated into machined components to remove sharp edges, improve assembly, accommodate mating components, or meet drawing requirements. Even relatively small deviations in chamfer size can affect part appearance, assembly, or compliance with engineering specifications.
The INSIZE 2944-1 provides a purpose-built method for checking these dimensions, making it easier for operators to verify chamfers consistently throughout the manufacturing process.
0.2–5 mm Measuring Range
The 2944-1 is designed for measuring chamfers from 0.2 to 5 mm (0.008–0.197"). This range makes the gauge particularly useful for small chamfers commonly found on precision-machined components.
The digital display provides a direct measurement reading, helping reduce interpretation errors associated with visual inspection.
Technical Specifications
| Specification | 2944-1 |
|---|---|
| Product Type | Digital Chamfer Height Gauge |
| Measuring Range | 0.2–5 mm / 0.008–0.197" |
| Accuracy | ±0.02 mm |
| Resolution | 0.01 mm / 0.0005" |
| Measurement Type | Chamfer Height |
| Manufacturer | INSIZE |
Typical Applications
The INSIZE 2944-1 is suitable for chamfer inspection in:
-
CNC machining
-
Precision machining
-
Metalworking
-
Tool and die manufacturing
-
Fabrication
-
Production quality control
-
Incoming inspection
-
Final inspection
-
General dimensional inspection
Why Use a Dedicated Chamfer Gauge?
A dedicated chamfer measuring tool provides a more direct approach to inspecting chamfer dimensions than attempting to estimate the feature with a general-purpose caliper or other conventional measuring instrument.
For production environments, the 2944-1 can help standardize chamfer inspections between operators and provide quick dimensional verification at the machine or inspection bench.
Built for Precision Inspection
The INSIZE 2944-1 combines a dedicated chamfer-measuring design with digital measurement and fine resolution in a compact inspection instrument. Its ±0.02 mm accuracy and 0.01 mm resolution make it appropriate for precision dimensional inspection where chamfer requirements must be verified against engineering drawings and production specifications.
Product Information
Model: 2944-1
Type: Digital Chamfer Height Gauge
Measuring Range: 0.2–5 mm / 0.008–0.197"
Accuracy: ±0.02 mm
Resolution: 0.01 mm / 0.0005"
Manufacturer Documentation
For complete technical information, refer to the official INSIZE documentation for the 2944 series.
